Delcam Powermill V6.008 SP2


[IMG]http://img44.**************/img44/5769/powermillsp33ji.jpg[/IMG]

PowerMILL - это мощный пакет для расчета черновых и чистовых управляющих программ для станков с ЧПУ. Он позволяет повысить производительность станков и, одновременно с этим, достичь наивысшего качества при изготовлении деталей и оснастки.
PowerMILL импортирует трехмерные модели, созданные в большинстве CAD-систем, и готовит программы для станков с ЧПУ.
Данные могут быть импортированы в следующих форматах:
•IGES
• VDA-FS
• ProENGINEER
• Unigraphics
• CADDS
• CATIA
• Parasolid
• ACIS
• STL
• STEP
•DGK
•DMT
Удобный и простой в использовании Windows-интерфейс обеспечивает доступ к исчерпывающему набору стратегий обработки и средств оптимизации даже оператору станка с ЧПУ. PowerMILL нетребователен к качеству данных и выполняет обработку без зарезов даже в случае наличия разрывов на поверхности модели.

[smoha456]

Delcam PowerMILL 10 (SP6/RC1/SP7)

Delcam PowerMILL - package for the preparation of high-control programs for CNC milling machines.This release is a continuation of distribution Delcam PowerMill 1910 SP5 + ext. Software. Features of pills and a full description can be found there.

More details...........................Show/Hide

PowerMILL 2010 RC1 Full 32bit (by SSQ) :

• RC1 - the latest version PM2010 which supports network licensing on the basis of Flex .. In RC2 and then Flex is no longer supported and crowbar on its basis will no longer ...
• If you have already installed the previous broken-off Delcam FlexLM Server (by SSQ) is a new crowbar to install the old server need only replace delcam.lic and delcam.exe
• PowerMILL 2010 RC1 Full 32bit can be installed on machines running Win32 and Win64 under
• The current version of PowerMILL 2010 64bit initially (starting from the first Bethke) is not supported by Flex .. so that the scrap to it (if anyone asks) - NO!
• This supports crowbar and PM1006 SP6 ..
• Addendum: (author eJonny) read carefully

Enhancements

1. Projects
• PowerMILL can now recover data from sessions which crashed even if no project was saved. Data will be always be saved in a temporary directory if no project name has been specified and this data can be recovered when PowerMILL is restarted.
• PowerMILL can continue to read a project even if it finds a corrupt or missing file in the project. If any entity references an entity that that powermill skipped over as a result, then that entity will be invalidated. PowerMILL will display an information log off any files it detected errors with, and any entities that were invalidated as a result.

2. Background Processing
• Toolpaths, Boundaries and Stock Models can now be calculated while the user continues to run PowerMILL. When the Queue button is pressed on the toolpath form processing will start, the icon in the tree will indicate when processing is complete. This is only available with an advanced NC licence.

3. Multi-Threading
• Many calculations are able use multi-threading, speeding up calculation by allowing PowerMILL to make full use of multi-core computers.

4. Calculation Speed
• Spiral machining calculates more quickly than in PowerMILL 9.

5. Toolpath Drawing Speed
• Framerates for scenes containing toolpaths, especially larger ones, have been improved. Also, contact point tracks are now selectable.
• The drawing of the "in progress" (pink) toolpath has been optimised so that toolpath calculations will run much more quickly. The more threads the calculation runs in, the greater the effect.

6. Memory
• Less memory is used when toolpaths are calculated, enabling machining to be performed on large models without running out of memory.

7. Graphical User Interface
• A setting on the Import page of the Option Form allows a user to choose the number of Most Recently Used Files
• The Drilling Form now uses the same type of user interface as 2D machining.
• PowerMILL has a new Status Bar.
• The Info Toolbar has been removed, along with the information fields on the Tool Toolbar. An improved Status bar has been implemented, which replaces the previous functionality. The Status bar uses the intelligent cursor to display the coordinates, allows workplane activation, hosts the grid and principal editing plane buttons (previously in the curve editor), and allows customisation of the information fields. The Status bar can also display user defined expressions, and will track changes in dependant parameters.
• The block now has a context menu which can be accessed by right clicking on it in the graphics window. However, this menu will only appear if no other entity, such as a toolpath or model, is under the mouse pointer at the same time.
• An option on the toolpath page is available for auto saving projects after every toolpath calculation.

8. Toolpath Verification
• Verification indicates more clearly the kinds of toolpath components that were found to collide or gouge.

9. Surfaces and Model
• The model length is now shown on the Model-> Properties Form

10. Tool Database
• Form and Routing tools can now be saved in the tool database.
• No restrictions exist on the number or type of shank components which can be stored in the tool database.
• Stock material which is not used by any records in the tool database can be deleted from the database.
• A Tool Holder Search Form has been created through which users can search for a holder and apply the selected holder to a specified tool.
• Functionality has been added on the existing Tool Database Search Form to allow the user to choose a holder from the database to use when creating tools from selected records.
• Functionality has been added to allow exporting tool holder data to the database independently.
• Tool User Parameters can now be saved in the Tool Database

11. Expressions and Parameters
• User parameters are now available for toolpaths. These can be added on the Toolpath Notes Form, raised using the right click menu on toolpaths, Edit-> Notes ...
• A conditional if command has been introduced as part of an expression, so for example the following is a valid expression:
• if (Tool.Type == 'tip_radius'; Tool.TipRadius; Tool.Diameter)
• This will give the value of the Tip Radius for a tip_radius tool, otherwise it will give the value of the tool diameter.

12. Graphical Interaction
• Toolpath start points may now be moved using simple graphical editing. This can be done both on individual segments and groups of segments where a closed cutting path is formed.
• Lead and link display may be switched off at any time during the process.
• The short cut keys now work while in a Graphics Mode such as Curve Collection or the Curve Editor.
• All the interactive workplane creation options that were part of the Curve Editor have been moved out onto the Status Bar. New modes have been added to allow creation of a workplane with respect to the block or selection. The Zoom to Box functionality now works correctly within special modes such as the Curve Editor or Workplane Creation modes.
• Graphical Block and Feature Editing is now much easier to use.
• The mouse wheel will now zoom centred at the current cursor location. This behaviour is customisable by modifying the resources in the graphics configuration file (dcam / sys / misc / graphics.con).

13. Blocks
• Blocks can now be locked to any workplane, not just world space. On the Block Form a new option menu allows the user to choose the coordinate system for the block. Choosing a named workplane locks the block to that workplane.

14. Setup Sheets
• The NC Program statistics variables PD_CutTime and PD_TotalTime can now be used on selected NC programs as well as all NC programs.
• A new variable project.basepath has been added. If the project is C: / programs / myprojects / pmproj then project.basepath is C: / programs / myprojects.

15. Electrodes
• PowerMILL can now read electrodes from a PowerSHAPE archive.

16. Toolpath Selection
• Components on active toolpaths can now be selected at any time without the need to change settings on the options form. Therefore, the Toolpath Selection page has been removed from the Options Form.

17. NC Programs
• In a macro it is now possible to create an NC Program from an active folder of toolpaths using the command
EDIT FOLDER; NCPROGRAM
• The feed and speed for each toolpath is now shown on the NC Program form in the toolpath list.

Product name : Delcam PowerMILL 10 (SP6/RC1/SP7)
Year : 2010
Version : SP 6 Codebase 1,117,242 (PM10) and 11.0.10.32.1129201 (PM2010)
OS Platform : Any Windows/Vista/7 (32-bit/64-bit)
System requirements : PowerMILL 2010 running on the same hardware as the PowerMILL 10. Multi-core computers give a significant boost in speed calculations.
Language : English & Russian
Treatment : Complete
Medicine : Present
File Size : 408 Mb
